JAN2N6300 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-213AA, TO-66-2
- Description: TRANS NPN DARL 60V 8A TO66
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N6300 Specifications:
- MfrPart.: JAN2N6300
- Mfr: Microchip Technology
- Description: TRANS NPN DARL 60V 8A TO66
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/539
- PartStatus: Active
- TransistorType: NPN - Darlington
- Current-Collector(Ic)(Max): 8 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 3V @ 80mA, 8A
- Current-CollectorCutoff(Max): 500µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 750 @ 4A, 3V
- Power-Max: 75 W
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-213AA, TO-66-2
- JAN2N6300 Microchip, TRANS NPN DARL 60V 8A TO66, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JAN2N6300, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
