JAN2N5686 Microchip NPN TRANSISTOR
JAN2N5686 Images
JAN2N5686 Images
JAN2N5686
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
  • Description: NPN TRANSISTOR
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
JAN2N5686 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
JAN2N5686 Specifications:
  • MfrPart.: JAN2N5686
  • Mfr: Microchip Technology
  • Description: NPN TRANSISTOR
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: Military, MIL-PRF-19500/464
  • PartStatus: Active
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 500 µA
  • Voltage-CollectorEmitterBreakdown(Max): 80 V
  • VceSaturation(Max)@IbIc: 5V @ 10A, 50A
  • Current-CollectorCutoff(Max): 500µA
  • DCCurrentGain(hFE)(Min)@IcVce: 15 @ 25A, 2V
  • Power-Max: 300 W
  • Frequency-Transition: -
  • OperatingTemperature: -55°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-204AA, TO-3
  • JAN2N5686 Microchip, NPN TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
