JAN2N3772 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
- Description: TRANS NPN 60V 20A TO-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N3772 Specifications:
- MfrPart.: JAN2N3772
- Mfr: Microchip Technology
- Description: TRANS NPN 60V 20A TO-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/518
- PartStatus: Discontinued at
- TransistorType: NPN
- Current-Collector(Ic)(Max): 20 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 4V @ 4A, 20A
- Current-CollectorCutoff(Max): 5mA
- DCCurrentGain(hFE)(Min)@IcVce: 15 @ 10A, 4V
- Power-Max: 6 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-204AA, TO-3
- JAN2N3772 Microchip, TRANS NPN 60V 20A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
