JAN2N2325A Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: TO-205AA, TO-5-3 Metal Can
- Description: SCR 150V TO5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N2325A Specifications:
- MfrPart.: JAN2N2325A
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: SCR 150V TO5
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs
- Package: Bulk
- Series: Military, MIL-STD-701
- PartStatus: Obsolete
- Voltage-OffState: 150 V
- Voltage-GateTrigger(Vgt)(Max): 600 mV
- Current-GateTrigger(Igt)(Max): 20 µA
- Voltage-OnState(Vtm)(Max): 2.2 V
- Current-OnState(It(AV))(Max): 1.6 A
- Current-OnState(It(RMS))(Max): -
- Current-Hold(Ih)(Max): 2 mA
- Current-OffState(Max): 10 µA
- Current-NonRepSurge5060Hz(Itsm): 15A @ 60Hz
- SCRType: Sensitive Gate
- OperatingTemperature: -65°C ~ 125°C
- MountingType: Through Hole
- Package/Case: TO-205AA, TO-5-3 Metal Can
- JAN2N2325A Microchip, SCR 150V TO5, Discrete Semiconductor Products~Thyristors - SCRs
