JAN2N2324U4 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: 3-SMD, No Lead
- Description: SCR 100V U4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N2324U4 Specifications:
- MfrPart.: JAN2N2324U4
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: SCR 100V U4
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs
- Package: Bulk
- Series: Military, MIL-PRF-19500/276
- PartStatus: Obsolete
- Voltage-OffState: 100 V
- Voltage-GateTrigger(Vgt)(Max): 800 mV
- Current-GateTrigger(Igt)(Max): 200 µA
- Voltage-OnState(Vtm)(Max): -
- Current-OnState(It(AV))(Max): -
- Current-OnState(It(RMS))(Max): -
- Current-Hold(Ih)(Max): 2 mA
- Current-OffState(Max): 10 µA
- Current-NonRepSurge5060Hz(Itsm): 15A @ 60Hz
- SCRType: Standard Recovery
- OperatingTemperature: -65°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 3-SMD, No Lead
- JAN2N2324U4 Microchip, SCR 100V U4, Discrete Semiconductor Products~Thyristors - SCRs
