JAN2N1485 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-233AA, TO-8-3 Lens Top Metal Can
- Description: TRANS NPN 40V 3A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N1485 Specifications:
- MfrPart.: JAN2N1485
- Mfr: Microchip Technology
- Description: TRANS NPN 40V 3A
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/207
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 3 A
- Voltage-CollectorEmitterBreakdown(Max): 40 V
- VceSaturation(Max)@IbIc: 750mV @ 40mA, 750mA
- Current-CollectorCutoff(Max): 15µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 35 @ 750mA, 4V
- Power-Max: 1.75 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-233AA, TO-8-3 Lens Top Metal Can
- JAN2N1485 Microchip, TRANS NPN 40V 3A, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JAN2N1485, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
