JAN1N3766R Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AB, DO-5, Stud
- Description: DIODE GEN PURP 800V 35A DO203AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN1N3766R Specifications:
- Manufacturer Product Number: JAN1N3766R
- Mfr: Microchip Technology
- Detailed Description: DIODE GEN PURP 800V 35A DO203AB
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/297
- Part Status: Active
- Diode Type: Standard, Reverse Polarity
- Voltage - DC Reverse (Vr) (Max): 800 V
- Current - Average Rectified (Io): 35A
- Voltage - Forward (Vf) (Max) @ If: 1.4 V @ 110 A
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 10 µA @ 800 V
- Capacitance @ Vr, F: -
- Mounting Type: Chassis, Stud Mount
- Package / Case: DO-203AB, DO-5, Stud
- Operating Temperature - Junction: -65°C ~ 175°C
- JAN1N3766R Microchip, DIODE GEN PURP 800V 35A DO203AB, Discrete Semiconductor Products~Diodes - Rectifiers - Single
JAN1N3766R, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
