CD5820 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: Die
- Description: DIODE SMALL-SIGNAL SCHOTTKY
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD5820 Specifications:
- Manufacturer Product Number: CD5820
- Mfr: Microchip Technology
- Detailed Description: DIODE SMALL-SIGNAL SCHOTTKY
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR)
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 20 V
- Current - Average Rectified (Io): 3A
- Voltage - Forward (Vf) (Max) @ If: 550 mV @ 3 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 100 µA @ 20 V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: Die
- Operating Temperature - Junction: -65°C ~ 125°C
- CD5820 Microchip, DIODE SMALL-SIGNAL SCHOTTKY, Discrete Semiconductor Products~Diodes - Rectifiers - Single
