APTSM120AM55CT1AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: SP1
- Description: POWER MODULE - SIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTSM120AM55CT1AG Specifications:
- MfrPart.: APTSM120AM55CT1AG
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: POWER MODULE - SIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 2 N-Channel (Dual), Schottky
- FETFeature: Silicon Carbide (SiC)
- DraintoSourceVoltage(Vdss): 1200V (1.2kV)
- Current-ContinuousDrain(Id)@25°C: 74A (Tc)
- RdsOn(Max)@IdVgs: 50mOhm @ 40A, 20V
- Vgs(th)(Max)@Id: 3V @ 2mA
- GateCharge(Qg)(Max)@Vgs: 272nC @ 20V
- InputCapacitance(Ciss)(Max)@Vds: 5120pF @ 1000V
- Power-Max: 470W
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP1
- APTSM120AM55CT1AG Microchip, POWER MODULE - SIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
APTSM120AM55CT1AG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
