APTMC120AM20CT1AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: SP1
- Description: MOSFET 2N-CH 1200V 143A SP1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTMC120AM20CT1AG Specifications:
- MfrPart.: APTMC120AM20CT1AG
- Mfr: Microchip Technology
- Description: MOSFET 2N-CH 1200V 143A SP1
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 2 N Channel (Phase Leg)
- FETFeature: Silicon Carbide (SiC)
- DraintoSourceVoltage(Vdss): 1200V (1.2kV)
- Current-ContinuousDrain(Id)@25°C: 143A (Tc)
- RdsOn(Max)@IdVgs: 17mOhm @ 100A, 20V
- Vgs(th)(Max)@Id: 2.3V @ 2mA (Typ)
- GateCharge(Qg)(Max)@Vgs: 360nC @ 20V
- InputCapacitance(Ciss)(Max)@Vds: 5960pF @ 1000V
- Power-Max: 600W
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP1
- APTMC120AM20CT1AG Microchip, MOSFET 2N-CH 1200V 143A SP1, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
APTMC120AM20CT1AG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
