APTM60H23FT1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: SP1
- Description: MOSFET 4N-CH 600V 20A SP1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTM60H23FT1G Specifications:
- MfrPart.: APTM60H23FT1G
- Mfr: Microchip Technology
- Description: MOSFET 4N-CH 600V 20A SP1
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 4 N-Channel (H-Bridge)
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 600V
- Current-ContinuousDrain(Id)@25°C: 20A
- RdsOn(Max)@IdVgs: 276mOhm @ 17A, 10V
- Vgs(th)(Max)@Id: 5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 165nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 5316pF @ 25V
- Power-Max: 208W
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP1
- APTM60H23FT1G Microchip, MOSFET 4N-CH 600V 20A SP1, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
APTM60H23FT1G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
