APTM50UM25SG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: Module
- Description: MOSFET N-CH 500V 149A MODULE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTM50UM25SG Specifications:
- MfrPart.: APTM50UM25SG
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 500V 149A MODULE
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Discontinued at
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 149A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 25mOhm @ 74.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 10mA
- GateCharge(Qg)(Max)@Vgs: 364 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 17500 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1250W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: Module
- APTM50UM25SG Microchip, MOSFET N-CH 500V 149A MODULE, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APTM50UM25SG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
