APTM50UM09FAG Microchip MOSFET N-CH 500V 497A SP6
APTM50UM09FAG Images
APTM50UM09FAG Images
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SP6
  • Description: MOSFET N-CH 500V 497A SP6
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
APTM50UM09FAG Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
APTM50UM09FAG Specifications:
  • MfrPart.: APTM50UM09FAG
  • Mfr: Microchip Technology
  • Description: MOSFET N-CH 500V 497A SP6
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 500 V
  • Current-ContinuousDrain(Id)@25°C: 497A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 10mOhm @ 248.5A, 10V
  • Vgs(th)(Max)@Id: 5V @ 30mA
  • GateCharge(Qg)(Max)@Vgs: 1200 nC @ 10 V
  • Vgs(Max): ±30V
  • InputCapacitance(Ciss)(Max)@Vds: 63300 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 5000W (Tc)
  • OperatingTemperature: -40°C ~ 150°C (TJ)
  • MountingType: Chassis Mount
  • SupplierDevicePackage: SP6
  • APTM50UM09FAG Microchip, MOSFET N-CH 500V 497A SP6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APTM50UM09FAG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
