APTM120UM70FAG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SP6
- Description: MOSFET N-CH 1200V 171A SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTM120UM70FAG Specifications:
- MfrPart.: APTM120UM70FAG
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1200V 171A SP6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 171A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 80mOhm @ 85.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 30mA
- GateCharge(Qg)(Max)@Vgs: 1650 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 43500 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 5000W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SP6
- APTM120UM70FAG Microchip, MOSFET N-CH 1200V 171A SP6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APTM120UM70FAG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
