APTM120U10SCAVG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SP6
- Description: MOSFET N-CH 1200V 116A SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTM120U10SCAVG Specifications:
- MfrPart.: APTM120U10SCAVG
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1200V 116A SP6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: POWER MOS 7®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 116A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 120mOhm @ 58A, 10V
- Vgs(th)(Max)@Id: 5V @ 20mA
- GateCharge(Qg)(Max)@Vgs: 1100 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 28900 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3290W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SP6
- APTM120U10SCAVG Microchip, MOSFET N-CH 1200V 116A SP6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
