APTM100UM65DAG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SP6
- Description: MOSFET N-CH 1000V 145A SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTM100UM65DAG Specifications:
- MfrPart.: APTM100UM65DAG
- Mfr: Microchip Technology
- Description: MOSFET N-CH 1000V 145A SP6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1000 V
- Current-ContinuousDrain(Id)@25°C: 145A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 78mOhm @ 72.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 20mA
- GateCharge(Qg)(Max)@Vgs: 1068 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 28500 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3250W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SP6
- APTM100UM65DAG Microchip, MOSFET N-CH 1000V 145A SP6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APTM100UM65DAG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
