APTGTQ100H65T3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MODULE 650V 100A 250W SP3F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGTQ100H65T3G Specifications:
- MfrPart.: APTGTQ100H65T3G
- Mfr: Microchip Technology
- Description: IGBT MODULE 650V 100A 250W SP3F
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: -
- Configuration: Full Bridge
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 100 A
- Power-Max: 250 W
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 100A
- Current-CollectorCutoff(Max): 100 µA
- InputCapacitance(Cies)@Vce: 6 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- APTGTQ100H65T3G Microchip, IGBT MODULE 650V 100A 250W SP3F, Discrete Semiconductor Products~Transistors - IGBTs - Modules
