APTGT75DU120TG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP4
- Description: IGBT MODULE 1200V 100A 350W SP4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT75DU120TG Specifications:
- MfrPart.: APTGT75DU120TG
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 100A 350W SP4
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Dual, Common Source
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 100 A
- Power-Max: 350 W
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 5.34 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP4
- APTGT75DU120TG Microchip, IGBT MODULE 1200V 100A 350W SP4, Discrete Semiconductor Products~Transistors - IGBTs - Modules
