APTGT600A60G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP6
- Description: IGBT MODULE 600V 700A 2300W SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT600A60G Specifications:
- MfrPart.: APTGT600A60G
- Mfr: Microchip Technology
- Description: IGBT MODULE 600V 700A 2300W SP6
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 700 A
- Power-Max: 2300 W
- Vce(on)(Max)@VgeIc: 1.8V @ 15V, 600A
- Current-CollectorCutoff(Max): 750 µA
- InputCapacitance(Cies)@Vce: 49 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP6
- APTGT600A60G Microchip, IGBT MODULE 600V 700A 2300W SP6, Discrete Semiconductor Products~Transistors - IGBTs - Modules
