APTGT50DSK120T3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP3
- Description: IGBT MODULE 1200V 75A 270W SP3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT50DSK120T3G Specifications:
- MfrPart.: APTGT50DSK120T3G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 1200V 75A 270W SP3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Configuration: Dual Buck Chopper
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 75 A
- Power-Max: 270 W
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 50A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 3.6 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP3
- APTGT50DSK120T3G Microchip, IGBT MODULE 1200V 75A 270W SP3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
