APTGT20DSK60T3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP3
- Description: IGBT MODULE 600V 32A 62W SP3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT20DSK60T3G Specifications:
- MfrPart.: APTGT20DSK60T3G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 600V 32A 62W SP3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Configuration: Dual Buck Chopper
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 32 A
- Power-Max: 62 W
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 20A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 1.1 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP3
- APTGT20DSK60T3G Microchip, IGBT MODULE 600V 32A 62W SP3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
