APTGT200A60T3AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP3
- Description: IGBT MODULE 600V 290A 750W SP3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT200A60T3AG Specifications:
- MfrPart.: APTGT200A60T3AG
- Mfr: Microchip Technology
- Description: IGBT MODULE 600V 290A 750W SP3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 290 A
- Power-Max: 750 W
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 200A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 12.3 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP3
- APTGT200A60T3AG Microchip, IGBT MODULE 600V 290A 750W SP3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APTGT200A60T3AG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
