APTGT150TL60G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP6
- Description: IGBT MODULE 600V 200A 480W SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT150TL60G Specifications:
- MfrPart.: APTGT150TL60G
- Mfr: Microchip Technology
- Description: IGBT MODULE 600V 200A 480W SP6
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Three Level Inverter
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 200 A
- Power-Max: 480 W
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 150A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 9.2 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP6
- APTGT150TL60G Microchip, IGBT MODULE 600V 200A 480W SP6, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APTGT150TL60G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
