APTGT150DA60T1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP1
- Description: IGBT MODULE 600V 225A 480W SP1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT150DA60T1G Specifications:
- MfrPart.: APTGT150DA60T1G
- Mfr: Microchip Technology
- Description: IGBT MODULE 600V 225A 480W SP1
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 225 A
- Power-Max: 480 W
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 150A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 9.2 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP1
- APTGT150DA60T1G Microchip, IGBT MODULE 600V 225A 480W SP1, Discrete Semiconductor Products~Transistors - IGBTs - Modules
