APTGT100A602G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP2
- Description: IGBT MODULE 600V 150A 340W SP2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGT100A602G Specifications:
- MfrPart.: APTGT100A602G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 600V 150A 340W SP2
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 150 A
- Power-Max: 340 W
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 100A
- Current-CollectorCutoff(Max): 50 µA
- InputCapacitance(Cies)@Vce: 6.1 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: SP2
- APTGT100A602G Microchip, IGBT MODULE 600V 150A 340W SP2, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APTGT100A602G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
