APTGLQ75H120T3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP1
- Description: IGBT MODULE 1200V 130A 385W SP1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGLQ75H120T3G Specifications:
- MfrPart.: APTGLQ75H120T3G
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 130A 385W SP1
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Full Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 130 A
- Power-Max: 385 W
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 75A
- Current-CollectorCutoff(Max): 50 µA
- InputCapacitance(Cies)@Vce: 4.4 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: SP1
- APTGLQ75H120T3G Microchip, IGBT MODULE 1200V 130A 385W SP1, Discrete Semiconductor Products~Transistors - IGBTs - Modules
