APTGLQ400A120T6G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP6
- Description: IGBT MODULE 1200V 700A 1900W SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGLQ400A120T6G Specifications:
- MfrPart.: APTGLQ400A120T6G
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 700A 1900W SP6
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 700 A
- Power-Max: 1900 W
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 400A
- Current-CollectorCutoff(Max): 200 µA
- InputCapacitance(Cies)@Vce: 24.6 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: SP6
- APTGLQ400A120T6G Microchip, IGBT MODULE 1200V 700A 1900W SP6, Discrete Semiconductor Products~Transistors - IGBTs - Modules
