APTGLQ25H120T1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MODULE 1200V 50A 165W SP1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGLQ25H120T1G Specifications:
- MfrPart.: APTGLQ25H120T1G
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 50A 165W SP1
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Full Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Power-Max: 165 W
- Vce(on)(Max)@VgeIc: 2.42V @ 15V, 25A
- Current-CollectorCutoff(Max): 50 µA
- InputCapacitance(Cies)@Vce: 1.43 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- APTGLQ25H120T1G Microchip, IGBT MODULE 1200V 50A 165W SP1, Discrete Semiconductor Products~Transistors - IGBTs - Modules
