APTGL700U120D4G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: D4
- Description: IGBT MODULE 1200V 910A 3000W D4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGL700U120D4G Specifications:
- MfrPart.: APTGL700U120D4G
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 910A 3000W D4
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 910 A
- Power-Max: 3000 W
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 600A
- Current-CollectorCutoff(Max): 4 mA
- InputCapacitance(Cies)@Vce: 37.2 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: D4
- APTGL700U120D4G Microchip, IGBT MODULE 1200V 910A 3000W D4, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APTGL700U120D4G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
