APTGL60DH120T3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP3
- Description: IGBT MODULE 1200V 80A 280W SP3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGL60DH120T3G Specifications:
- MfrPart.: APTGL60DH120T3G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 1200V 80A 280W SP3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Configuration: Asymmetrical Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 80 A
- Power-Max: 280 W
- Vce(on)(Max)@VgeIc: 2.25V @ 15V, 50A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 2.77 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP3
- APTGL60DH120T3G Microchip, IGBT MODULE 1200V 80A 280W SP3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APTGL60DH120T3G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
