APTGL475U120DAG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP6
- Description: IGBT MODULE 1200V 610A 2307W SP6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGL475U120DAG Specifications:
- MfrPart.: APTGL475U120DAG
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 610A 2307W SP6
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 610 A
- Power-Max: 2307 W
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 400A
- Current-CollectorCutoff(Max): 4 mA
- InputCapacitance(Cies)@Vce: 24.6 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP6
- APTGL475U120DAG Microchip, IGBT MODULE 1200V 610A 2307W SP6, Discrete Semiconductor Products~Transistors - IGBTs - Modules
