APTGFQ25H120T2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP2
- Description: IGBT MODULE 1200V 40A 227W SP2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGFQ25H120T2G Specifications:
- MfrPart.: APTGFQ25H120T2G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 1200V 40A 227W SP2
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: NPT and Fieldstop
- Configuration: Full Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 40 A
- Power-Max: 227 W
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 25A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 2.02 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -
- MountingType: Through Hole
- Package/Case: SP2
- APTGFQ25H120T2G Microchip, IGBT MODULE 1200V 40A 227W SP2, Discrete Semiconductor Products~Transistors - IGBTs - Modules
