APTGF90TA60PG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP6
- Description: IGBT MODULE 600V 110A 416W SP6P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGF90TA60PG Specifications:
- MfrPart.: APTGF90TA60PG
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 600V 110A 416W SP6P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Configuration: Three Phase
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 110 A
- Power-Max: 416 W
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 90A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 4.3 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -
- MountingType: Chassis Mount
- Package/Case: SP6
- APTGF90TA60PG Microchip, IGBT MODULE 600V 110A 416W SP6P, Discrete Semiconductor Products~Transistors - IGBTs - Modules
