APTGF75SK60D1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: D1
- Description: IGBT MODULE 600V 100A 355W D1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGF75SK60D1G Specifications:
- MfrPart.: APTGF75SK60D1G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 600V 100A 355W D1
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Discontinued at
- IGBTType: NPT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Power-Max: 355 W
- Vce(on)(Max)@VgeIc: 2.45V @ 15V, 75A
- Current-CollectorCutoff(Max): 500 µA
- InputCapacitance(Cies)@Vce: 3.3 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: D1
- APTGF75SK60D1G Microchip, IGBT MODULE 600V 100A 355W D1, Discrete Semiconductor Products~Transistors - IGBTs - Modules
APTGF75SK60D1G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
