APTGF300SK120D3G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: D-3 Module
- Description: IGBT MODULE 1200V 420A 2100W D3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGF300SK120D3G Specifications:
- MfrPart.: APTGF300SK120D3G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 1200V 420A 2100W D3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 420 A
- Power-Max: 2100 W
- Vce(on)(Max)@VgeIc: 3.7V @ 15V, 300A
- Current-CollectorCutoff(Max): 5 mA
- InputCapacitance(Cies)@Vce: 19 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -
- MountingType: Chassis Mount
- Package/Case: D-3 Module
- APTGF300SK120D3G Microchip, IGBT MODULE 1200V 420A 2100W D3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
