APTGF180DA60TG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP4
- Description: IGBT MODULE 600V 220A 833W SP4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGF180DA60TG Specifications:
- MfrPart.: APTGF180DA60TG
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 600V 220A 833W SP4
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 220 A
- Power-Max: 833 W
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 180A
- Current-CollectorCutoff(Max): 300 µA
- InputCapacitance(Cies)@Vce: 8.6 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -
- MountingType: Chassis Mount
- Package/Case: SP4
- APTGF180DA60TG Microchip, IGBT MODULE 600V 220A 833W SP4, Discrete Semiconductor Products~Transistors - IGBTs - Modules
