APTGF165SK60D1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: D1
- Description: IGBT MODULE 600V 230A 730W D1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGF165SK60D1G Specifications:
- MfrPart.: APTGF165SK60D1G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IGBT MODULE 600V 230A 730W D1
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 230 A
- Power-Max: 730 W
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 200A
- Current-CollectorCutoff(Max): 500 µA
- InputCapacitance(Cies)@Vce: 9 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -
- MountingType: Chassis Mount
- Package/Case: D1
- APTGF165SK60D1G Microchip, IGBT MODULE 600V 230A 730W D1, Discrete Semiconductor Products~Transistors - IGBTs - Modules
