APTGF150A120T3AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SP3
- Description: IGBT MODULE 1200V 210A 1041W SP3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTGF150A120T3AG Specifications:
- MfrPart.: APTGF150A120T3AG
- Mfr: Microchip Technology
- Description: IGBT MODULE 1200V 210A 1041W SP3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 210 A
- Power-Max: 1041 W
- Vce(on)(Max)@VgeIc: 3.7V @ 15V, 150A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 9.3 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -
- MountingType: Chassis Mount
- Package/Case: SP3
- APTGF150A120T3AG Microchip, IGBT MODULE 1200V 210A 1041W SP3, Discrete Semiconductor Products~Transistors - IGBTs - Modules
