APTC80DA15T1G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SP1
- Description: MOSFET N-CH 800V 28A SP1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTC80DA15T1G Specifications:
- MfrPart.: APTC80DA15T1G
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 800V 28A SP1
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 28A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 150mOhm @ 14A, 10V
- Vgs(th)(Max)@Id: 3.9V @ 2mA
- GateCharge(Qg)(Max)@Vgs: 180 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 4507 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 277W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SP1
- APTC80DA15T1G Microchip, MOSFET N-CH 800V 28A SP1, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
