APTC80A15SCTG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: SP4
- Description: MOSFET 2N-CH 800V 28A SP4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTC80A15SCTG Specifications:
- MfrPart.: APTC80A15SCTG
- Mfr: Microchip Technology
- Description: MOSFET 2N-CH 800V 28A SP4
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 2 N-Channel (Half Bridge)
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 800V
- Current-ContinuousDrain(Id)@25°C: 28A
- RdsOn(Max)@IdVgs: 150mOhm @ 14A, 10V
- Vgs(th)(Max)@Id: 3.9V @ 2mA
- GateCharge(Qg)(Max)@Vgs: 180nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 4507pF @ 25V
- Power-Max: 277W
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP4
- APTC80A15SCTG Microchip, MOSFET 2N-CH 800V 28A SP4, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
APTC80A15SCTG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
