APT85GR120B2 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 170A 962W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT85GR120B2 Specifications:
- MfrPart.: APT85GR120B2
- Mfr: Microchip Technology
- Description: IGBT 1200V 170A 962W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 170 A
- Current-CollectorPulsed(Icm): 340 A
- Vce(on)(Max)@VgeIc: 3.2V @ 15V, 85A
- Power-Max: 962 W
- SwitchingEnergy: 6mJ (on), 3.8mJ (off)
- InputType: Standard
- GateCharge: 660 nC
- Td(on/off)@25°C: 43ns/300ns
- TestCondition: 600V, 85A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT85GR120B2 Microchip, IGBT 1200V 170A 962W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT85GR120B2, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
