APT80SM120S Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D3Pak
- Description: SICFET N-CH 1200V 80A D3PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT80SM120S Specifications:
- MfrPart.: APT80SM120S
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: SICFET N-CH 1200V 80A D3PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 55mOhm @ 40A, 20V
- Vgs(th)(Max)@Id: 2.5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 235 nC @ 20 V
- Vgs(Max): +25V, -10V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 625W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D3Pak
- APT80SM120S Microchip, SICFET N-CH 1200V 80A D3PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT80SM120S, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
