APT80GA90S Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- Description: IGBT PT MOS 8 SINGLE 900 V 80 A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT80GA90S Specifications:
- MfrPart.: APT80GA90S
- Mfr: Microchip Technology
- Description: IGBT PT MOS 8 SINGLE 900 V 80 A
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 8®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- Current-Collector(Ic)(Max): 145 A
- Current-CollectorPulsed(Icm): 239 A
- Vce(on)(Max)@VgeIc: 3.1V @ 15V, 47A
- Power-Max: 625 W
- SwitchingEnergy: 1.625mJ (on), 1.389mJ (off)
- InputType: Standard
- GateCharge: 200 nC
- Td(on/off)@25°C: 18ns/149ns
- TestCondition: 600V, 47A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
- APT80GA90S Microchip, IGBT PT MOS 8 SINGLE 900 V 80 A, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT80GA90S, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
