APT80GA90B Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 900V 145A 625W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT80GA90B Specifications:
- MfrPart.: APT80GA90B
- Mfr: Microchip Technology
- Description: IGBT 900V 145A 625W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- Current-Collector(Ic)(Max): 145 A
- Current-CollectorPulsed(Icm): 239 A
- Vce(on)(Max)@VgeIc: 3.1V @ 15V, 47A
- Power-Max: 625 W
- SwitchingEnergy: 1652µJ (on), 1389µJ (off)
- InputType: Standard
- GateCharge: 200 nC
- Td(on/off)@25°C: 18ns/149ns
- TestCondition: 600V, 47A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT80GA90B Microchip, IGBT 900V 145A 625W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
