APT80GA60B Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 143A 625W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT80GA60B Specifications:
- MfrPart.: APT80GA60B
- Mfr: Microchip Technology
- Description: IGBT 600V 143A 625W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 143 A
- Current-CollectorPulsed(Icm): 240 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 47A
- Power-Max: 625 W
- SwitchingEnergy: 840µJ (on), 751µJ (off)
- InputType: Standard
- GateCharge: 230 nC
- Td(on/off)@25°C: 23ns/158ns
- TestCondition: 400V, 47A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT80GA60B Microchip, IGBT 600V 143A 625W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT80GA60B, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
