APT75GP120J Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: ISOTOP
- Description: IGBT MOD 1200V 128A 543W ISOTOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT75GP120J Specifications:
- MfrPart.: APT75GP120J
- Mfr: Microchip Technology
- Description: IGBT MOD 1200V 128A 543W ISOTOP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 128 A
- Power-Max: 543 W
- Vce(on)(Max)@VgeIc: 3.9V @ 15V, 75A
- Current-CollectorCutoff(Max): 1 mA
- InputCapacitance(Cies)@Vce: 7.04 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: ISOTOP
- APT75GP120J Microchip, IGBT MOD 1200V 128A 543W ISOTOP, Discrete Semiconductor Products~Transistors - IGBTs - Modules
