APT75GP120B2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 1200V 100A 1042W TMAX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT75GP120B2G Specifications:
- MfrPart.: APT75GP120B2G
- Mfr: Microchip Technology
- Description: IGBT 1200V 100A 1042W TMAX
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 3.9V @ 15V, 75A
- Power-Max: 1042 W
- SwitchingEnergy: 1620µJ (on), 2500µJ (off)
- InputType: Standard
- GateCharge: 320 nC
- Td(on/off)@25°C: 20ns/163ns
- TestCondition: 600V, 75A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT75GP120B2G Microchip, IGBT 1200V 100A 1042W TMAX, Discrete Semiconductor Products~Transistors - IGBTs - Single
