APT75GN60BDQ2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT FIELDSTOP SINGLE 600V 75A T
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT75GN60BDQ2G Specifications:
- MfrPart.: APT75GN60BDQ2G
- Mfr: Microchip Technology
- Description: IGBT FIELDSTOP SINGLE 600V 75A T
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 155 A
- Current-CollectorPulsed(Icm): 225 A
- Vce(on)(Max)@VgeIc: 1.85V @ 15V, 75A
- Power-Max: 536 W
- SwitchingEnergy: 2.5mJ (on), 2.14mJ (off)
- InputType: Standard
- GateCharge: 485 nC
- Td(on/off)@25°C: 47ns/385ns
- TestCondition: 400V, 75A, 1Ohm, 15V
- ReverseRecoveryTime(trr): 25 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT75GN60BDQ2G Microchip, IGBT FIELDSTOP SINGLE 600V 75A T, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT75GN60BDQ2G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
