APT70GR65B Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 650V 134A 595W TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT70GR65B Specifications:
- MfrPart.: APT70GR65B
- Mfr: Microchip Technology
- Description: IGBT 650V 134A 595W TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 134 A
- Current-CollectorPulsed(Icm): 260 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 70A
- Power-Max: 595 W
- SwitchingEnergy: 1.51mJ (on), 1.46mJ (off)
- InputType: Standard
- GateCharge: 305 nC
- Td(on/off)@25°C: 19ns/170ns
- TestCondition: 433V, 70A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT70GR65B Microchip, IGBT 650V 134A 595W TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT70GR65B, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
