APT68GA60LD40 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 600V 121A 520W TO-264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT68GA60LD40 Specifications:
- MfrPart.: APT68GA60LD40
- Mfr: Microchip Technology
- Description: IGBT 600V 121A 520W TO-264
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 8™
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 121 A
- Current-CollectorPulsed(Icm): 202 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 40A
- Power-Max: 520 W
- SwitchingEnergy: 715µJ (on), 607µJ (off)
- InputType: Standard
- GateCharge: 198 nC
- Td(on/off)@25°C: 21ns/133ns
- TestCondition: 400V, 40A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): 22 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- APT68GA60LD40 Microchip, IGBT 600V 121A 520W TO-264, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT68GA60LD40, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
